SM400, SM600, SM800 sandwich machines are efficient and flexible system for wide range of sandwich products.
- stainless steel construction
- designed for round, square and rectangular sandwiches
- capacities up to 8.000 pcs/h
- double cutting arm system, servo driven
- „no biscuit – no ice cream“ system as standard
- photocell for print registration
- single or double reel holder/s
- changeable biscuit magazines for swift product change
- stainless steel sanitary constructed top and bottom biscuit stations to accommodate a large variety of biscuits. These stations can be reased and lowered - to start and stop biscuit feeding.
- sanitary constructed vertical extrusion station, with nozzle holder. The nozzles are available in a wide variety of configurations to accommodate any size of sandwich in 1-2-3 colors.
- dual hot wire cutter, which is servo driven and controlled by central PLC of the machine.
- completely wrapped product is discharged onto horizontal conveyor belt.
- all operations of SM machine are controlled by central PLC unit. Operator interface is 5“ color touch screen.
- Models available: SM400, SM600, SM800.
